Small in size – big on performance!

Flexibility and performance in one compact machine.

It’s what many timber construction companies from around the world have been waiting for: Hundegger has once again added machines with modest space requirements to its product range.

The ROBOT-Compact 650 allows economical and professional joinery even for companies with limited space and small production quantities. Efficiency is achieved on the one hand through the proven use of the 6-axis robot unit of the ROBOT-Drive with automated tool changer, and on the other thanks to a sophisticated product concept.

Our main aim in development was maximum flexibility coupled with minimum use of space.
Hundegger ROBOT-Compact 650:

Professional joinery – compact and flexible

The ROBOT-Compact

ROBOT-Compact 650
- For cross-sections from 20 x 60 mm to 300 x 650 mm - for all requirements up to the joinery of laminated girders and cross laminated timber

HIGHLIGHTS OF THE ROBOT-Compact 650

Today, efficient and profitable production is a decisive factor in the success of any company. This is precisely why the ROBOT-Compact 650 was uncompromisingly fitted with the innovative 6-axis robot unit.Automatic joinery leads to a real boost in capacity.
The simple formula for success is: Produce more parts with fewer employees and in a shorter time.

Precision and profitability cleverly combined.

The central element is the patented 6-axis robot unit with 28 tool slots.
You can use the ROBOT-Compact 650 to complete all conventional operations in a single pass, without part rotation or turning.

Patented 6-axis ROBOT unit

[Translate to Englisch (USA):] [Translate to Englisch (Deutschland):] [Translate to Deutsch (Deutschland):] Schlitzgerät

The patented 6-axis ROBOT unit with a speed range from 0 to 12,000 rpm and up to 28 freely selectable tools.

The ROBOT-Compact tool magazine.

The magazine of the tool changer is designed to hold up to 28 different tools with a usable length of up to 420 mm.

Short part flap with conveyor belt

[Translate to Englisch (USA):] [Translate to Englisch (Deutschland):] [Translate to Deutsch (Deutschland):] Bauteilausgabe

A transport conveyor belt is used to transport short parts of the machine size to the operator side. There, the parts can be easily received by the operator in the form of individual or multiple parts.

HOW YOU BENEFIT:

Flexibility and performance compactly combined in the smallest space
Unmatched flexibility for bespoke projects
For cross-sections from 20 x 60 mm to 300 x 650 mm
6-axis technology = processing on 6 sides in a single pass
6-axis technology = utilization of 28 different tools

VIDEO ROBOT-Compact 650

Download Brochure

Processing examples ROBOT-Compact 650

With a huge increase in flexibility, quality and efficiency.

PERFECT JOINERY

CAPACITY INCREASE WITH SIMULTANEOUS COST REDUCTION

Whether carpentry joinery, timber frame construction, log house construction, half-timber house construction, glulam construction or the joining of cross laminated timber – the 6-axis robot unit with its flexible tool changer is perfectly equipped for every challenge. Trimming, grooving, drilling, milling, slotting or marking: with the right tool in the magazine, the processing possibilities are almost unlimited. The infinitely variable speed range of the ROBOT spindle in combination with different tool approach strategies and processing cycles selected according to the specific requirement ensure surfaces up to visual quality.

The high flexibility is one of the K2-Industry’s strengths. Whatever is needed in carpentry joinery can be produced quickly and cost-effectively.

[Translate to Englisch (USA):] [Translate to Englisch (Deutschland):] [Translate to Deutsch (Deutschland):] Auskehlung

[Translate to Englisch (USA):] [Translate to Englisch (Deutschland):] [Translate to Deutsch (Deutschland):] Steigende Kerve

[Translate to Englisch (USA):] [Translate to Englisch (Deutschland):] [Translate to Deutsch (Deutschland):] Klingschrot

[Translate to Englisch (USA):] [Translate to Englisch (Deutschland):] [Translate to Deutsch (Deutschland):] Mehrspindelbohrer

[Translate to Englisch (USA):] [Translate to Englisch (Deutschland):] [Translate to Deutsch (Deutschland):] Profil

The high individualization of the ROBOT-Drive concept proves its worth every day anew.

Precision and profitability cleverly combined.
The ROBOT-Compact 650 allows economical and professional joinery even for companies with limited space and small production quantities.

Modular design

For your optimal performance boost

Main units

An unbeatable duo:
The ROBOT unit and the ROBOT-Compact tool magazine.

Options

In addition to the basic equipment, the ROBOT-Compact offers various additional options such as slot cutter, labelling system and label printer.

The ROBOT-Compact layout

Compact solutions for all requirements.

ROBOT-Compact 650 with automatic infeed standard, timber length 13 m and timber outfeed 13 m

ROBOT-Compact 650 with automatic infeed, buffer, timber length 13 m and timber outfeed 13 m

ROBOT-Compact 650 with automatic infeed, buffer and lifting table for timber length 13 m and placement conveyor for timber length 13 m

Automation of the Hundegger ROBOT-Compact 650

Flexible thanks to a modular system

Automatic infeed buffer

Our automatic infeed buffer offers a further boost to productivity. The operator can place several pieces of timber at the same time on the loading cross conveyor with stainless-steel slatband chains. The system automatically feeds these pieces of timber separately to the processing zone. This allows the operator to perform other tasks.

Lift table optionally with automatic stacking

The hydraulic lift table is installed upstream of the infeed cross conveyor. Stacks of timber can be placed on the lift table and raised to the desired height.
This enables timber to be fed in continuously level with the infeed cross conveyor.

The outfeed system

Finished parts will be gently pushed onto a storage rack. For heavy components an optional chain drive is available to support the discharge. Alternatively the storage rack can be replaced by a conveyor that automatically transfers the finished parts to further work areas.
